How to solve the major reasons for the beating of the tail top of the spinning machine?

The tail top of the spinning machine tool is prone to jumping. The following are the reasons for the jumping of the tail top of the machine tool and the corresponding solutions.

1. The operation of the machine tool is wrong, the cutter wheel hits the tail shaft, resulting in deformation of the tail shaft.

2. The precision of the tail top and the tail top shaft is not high enough.

3. The bearing of the tail top shaft is worn and damaged, and there will be abnormal noise when the tail top shaft rotates.

4. The assembly accuracy of the spindle mold and flange is not good, which drives the tail top to jump.

What effect does the tail top jump of the spinning machine have on the spinning product?

The beating of the tail top of the spinning machine will have a certain impact on the spinning forming, mainly due to the following factors:

1. Due to the poor elongation of the material and the large force of the stainless steel, when the tail top jumps, the root will break due to the uneven force of the material.

2. The hardness of the aluminum material is small, and the bottom of the spinning product will be scratched due to the beating of the tail top during the spinning process.

3. The tail top jump will cause insufficient contact area between the material and the tail top, and the spinning force will cause the material to move.

4. The runout of the tail top will affect the dimensional accuracy of the product after molding, and the diameter accuracy of the bottom of the product will become worse.

The main reason for the sticking of the main shaft of the spinning machine during the large-scale strong spinning process

1. The weight of the spinning mold is not reduced, and the quality of the mold is too large.

2. The belt of the spindle motor becomes loose after being used for a long time, just adjust the pre-tightening force.
